GK7080FC-BMSC3-2LESL

8MP Starlight Full Color Fixed Bullet Camera

Feature

✅ Video Output Mode：8MP(AHD/TVI/CVI)@15fps
✅ 1/2.8” SONY Starvis Back-illuminated CMOS sensor
✅ Support Warm white (4000K)｜Light Distance：up to 30m
✅ 3.6mm fixed lens｜optional：2.8 /6.0 mm
✅ Support OSD Menu
✅ Support WDR
✅ Housing：Metal｜IP67

Specification

Model：GK7080FC-BMSC3-2LESL

Image Sensor：1/2.8" SONY Starvis Back-illuminated CMOS Sensor

Master chip：Eyenix EN772 High Performance ISP

Image Resolution：8M：3840x2160｜5M：2592x1944｜4M：2560x1440｜2M：1920x1080

Video Output Mode：AHD：8M@15fps｜5M@20fps/12.5fps｜4M/2M@30fps/25fps;

CVI：8M@15fps/12.5fps｜4M/2M@30fps/25fps

TVI：8M@15fps/12.5fps｜5M@20fps/12.5fps｜4M/2M@30fps/25fps

TV System：NTSC｜PAL

Electronic Shutter：Auto

Minimum Illumination：0.005Lux

Scanning System：Progressive Scan

Focus Length：3.6 mm｜optional：2.8 /6.0 mm

Focus Control：Fixed

Lens Type：Fixed

IR Cut Filter：YES

Infrared LED：Support Warm white (4000K)

Light Distance：30M

IR Status：AGC auto control

Starlight：Support

Day/Night：ON｜OFF

OSD Menu：Support

WDR：Support

UTC：Support

Noise Reduction：AI-DNR

Gain Control：Auto

White Balance：AUTO｜MANUAL

Coaxial Audio：No

Material/Color：Metal｜White

Waterproof：IP67

Bracket：Yes

Operation Temperature：-10ºC~60ºC｜RH50% Max

Storage Temperature：-20ºC~60ºC｜RH50% Max

Power Source：DC12V ±10% 450mA

Dimension：70(W) x 67.5(H) x 169(L) mm

Weight：600g

Certification：CE｜FCC｜IP67
