Model：GK7080AOC-BMMB3-4LFKE

Image Sensor：1/2.5” Low illumination back-illuminated K17 CMOS sensor

Master chip：Fullhan FH8538E 8M High Performance ISP

Image Resolution：8M：3840x2160｜5M：2592x1944｜4M：2560x1440｜2M：1920x1080

Video Output Mode：AHD/TVI：8M@15/12.5fps｜5M@20/12.5fps｜4M@30/20/15fps｜2M@30/20fps

CVI：8M@15/12fps｜5M@20/12.5fps｜4M@30/25fps｜2M@30/25fps

TV System：NTSC｜PAL

Electronic Shutter：Auto

Minimum Illumination：0.01Lux

Scanning System：Progressive  Scan

Focus Length：3.6 mm｜optional：2.8 /6.0 mm

Focus Control：Fixed

Lens Type：Fixed

IR Cut Filter：YES

Infrared LED：Support Warm white (4000K)

Light Distance：50M

IR Status：AGC auto control

Starlight：Support

Day/Night：Full color｜Black and white

OSD Menu：Support

WDR：Support

UTC：Support

Noise Reduction：AI-DNR

White Balance：AUTO｜MANUAL

Gain Control：Auto

Audio Input：Built-in microphone

Coaxial Audio：Support

Material/Color：Metal｜White

Waterproof：IP67

Bracket：Yes

Operation Temperature：-30ºC~50ºC｜RH50% Max

Storage Temperature：-20ºC~60ºC｜RH50% Max

Power Source：DC12V ±10% 450mA

Dimension：268(W) x 95(H) x 88(D)mm

Weight：1500g

Certification：CE｜FCC｜IP67
