Model：GK5830FC-BMSD3-2LFG

Image Sensor：1/2.9” Progressive scan CMOS Sensor

Resolution：3MP

Effective Pixels：2304(H) x 1296(V)

Compression：H.264｜H.264+｜H.265｜H.265+｜JPEG｜AVI

Audio Encoding Format：G711A｜G711U｜AAC

TV System：NTSC｜PAL

Electronic Shutter Time：1/25(30)~1/10,000s

Minimum Illumination：0.01 Lux

S/N Ratio：60dB

Scanning System：Progressive

Video Output：Network

Reset Button：NO

Focus Length：Standard: 3.6 mm | Optional: 2.8 / 6.0 mm

Focus Control：Fixed

Lens Type：Fixed

Lens Pixels：3MP

Infrared LED：Support Warm light LED 4000K

Infrared Distance：30M

IR Status：Auto

IR Power On：Smart｜Manual｜Timed mode

Ethernet：1xRJ45 10/100M

Protocol：TCP/IP｜ICMP｜HTTP｜HTTPS｜FTP｜DHCP｜DNS｜DDNS｜RTP｜RTSP｜RTCP｜PPPoE｜NTP｜UPnP

｜SMTP｜UDP

ONVIF：ONVIF 2.4 (Profile S /T /G)

P2P：Support

POE：Support IEEE 802.3af

Video Delay：0.3s (Within the Lan)

Main Stream 1=：2304x1296@30fps

Main Stream 2：1920x1080@30fps

Main Stream 3：720x480@30fps

Sub Stream 1：1280x720@30fps

Sub Stream 2：720x480@30fps

Sub Stream 3：NO

Tri Stream：NO

IE Brower：IE8~11｜Chrome｜Firefox｜safari

Smart Phone：iPhone｜iPad｜Android｜Android Pad

Intelligent Analysis：Intrusion Detection

Day/Night：Color｜B&W

Full Color：Support

Image Config：Saturation｜Brightness｜Contrast｜Sharpness｜Mirror｜3D NR｜White Balance｜FLK｜Video Tampering

｜HLC｜Distortion

ROI：Support

Defog  Mode：Support

BLC：Support

WDR：HDR 50dB

Motion Detection：Support

Privacy  Masking：3 Rectangular Zone

Recording Mode：NVR｜VMS｜WEB｜SD card

Cloud Storage：Support for Google Cloud Storage settings

SD Card Slot：Internal｜Support Max 512GB

Audio：Built-in MIC

Alarm：NO

RS485：NO

Housing：Metal

Bracket：Anti-cut Bracket

Operation Temperature：-20ºC ~ +60ºC

Storage Temperature：-20ºC ~ +60ºC

Power：DC12V±10%, 1000mA

Dimension：154(W) x 70.5(H) x 70.5(D) mm

Weight：370g

Certification：CE｜FCC｜IP67
