GK7050ECO-CMSD3-2LFP

5MP Starlight Full Color Fixed Dome Camera

Feature

✅ Video Output Mode：5MP(AHD/TVI)@20fps｜4M：(CVI)@30fps
✅ 1/3” Low illumination back-illuminated F37P CMOS sensor
✅ Support Warm white (4000K)｜Light Distance：up to 30m
✅ 3.6 mm Fixed lens｜optional：2.8 /6.0 mm
✅ Support starlight full color
✅ Support WDR
✅ Housing: Metal, IP67

Specification

Model：GK7050ECO-CMSD3-2LFP

Image Sensor：1/3” Low illumination back-illuminated F37P CMOS sensor

Master chip：Fullhan FH8538E 5M High Performance ISP

Image Resolution：5M：2592x1944｜4M：2560x1440｜2M：1920x1080

Video Output Mode：AHD/TVI：5M@20fps｜4M@30fps｜2M@30fps

CVI：4M@30fps｜2M@30fps

TV System：NTSC｜PAL

Electronic Shutter：Auto

Minimum Illumination：0.01Lux

Scanning System：Progressive Scan

Focus Length：3.6 mm｜optional：2.8 /6.0 mm

Focus Control：Fixed

Lens Type：Fixed

IR Cut Filter：YES

Infrared LED：Support Warm white (4000K)

Light Distance：30M

IR Status：AGC auto control

Starlight：Support

Day/Night：Full color｜Black and white

OSD Menu：NO

WDR：Support

UTC：Support

Noise Reduction：AI-DNR

White Balance：AUTO｜MANUAL

Gain Control：Auto

Coaxial Audio：No

Material/Color：Metal｜White

Waterproof：IP67

Bracket：Yes

Operation Temperature：-30ºC~50ºC｜RH50% Max

Storage Temperature：-20ºC~60ºC｜RH50% Max

Power Source：DC12V ±10% 450mA

Dimension：⌀ 108 x 85(H) mm

Weight：400g

Certification：CE｜FCC｜IP67
