Thermal infrared and facial recognition tablet network camera
Feature
✅ Starlight high-quality image (1920x1080)
✅ Infrared temperature sensor (80x60), H.265/H.264/MJPEG compression coding technology
✅ Built-in non-contact high-precision thermal imaging module + living body detection two-in-one
✅ Human body temperature measurement range -10°C~50°C, accuracy ±0.3°C
✅ Support human body temperature overlay, picture overlay
✅ Support body temperature detection
✅ Support mask detection
✅ High-precision temperature measurement: ±0.3°C, Taiwan TAF certification
✅ Built-in FACE++ deep learning face recognition algorithm｜100ms fast recognition
✅ Support 50,000 face databases
✅ 8-inch high-definition LCD screen
✅ Local alarm output after abnormal temperature
✅ Face recognition, body temperature detection, mask recognition
✅ Can record identity information and temperature information, save traceability
✅ Support Wigan protocol
Specification
Model：GK5200RT
Display
Display Screen：8” LCD
Thermal
Image Sensor：Thermal induction infrared temperature sensor
Effective Pixels：80(H) x 60(V)
Field of View：118°
Measuring Range：30°C~+50°C
Spectral Range：8~14μm
Accuracy：± 0.3°C (-10 ~ +50°C)
Camera
Image Sensor：1/2.8” 2MP starlight level low illumination CMOS sensor
Resolution：1920(H) x 1080(V)
Electronic Shutter：1/5~1/20,000s
Min illumination：Color：0.005Lux@F1.2｜B/W：0.001Lux@F1.2
Wide Dynamic：≥120dB
S/N Ratio：≥46dB (AGC OFF)
White Balance：Auto｜indoor｜outdoor｜sodium lamp mode｜manual
D/N Reduction：Support DNR｜3DNR
Day & Night Mode：Fixed color
Lens Type：Fixed lens
focal Length：3.6 mm
Maximum Aperture：F2.0
Field View：118°
Temperature Measurement
Measurement Mode：Support temperature measurement in the whole area and area
Accuracy：Max ±0.3°C
Abnormal Alarm：High temperature/low temperature/temperature difference
Audio&Video
Compression Format：H.265｜H.264｜MJPEG
Image Resolution：Main：1920x1080｜1280x720｜720x576
Sub：640x480｜352x288｜320x240｜176x144
MJPEG：1920x1080｜1280x720｜OFF
Output Bit Rate：Fixed code stream (CBR) or variable code stream (VBR), code stream setting
range: 32Kbps~10Mbps
Audio Compression：G711｜PCM
OSD：Support channel name/date/time
Smart Computing
Face Database：Maximum 50,000 sheets, support group management
Recognition Speed：≤300ms
Live Detection：Support
External Port
Power Input：DC12V-2A
Network Port：1xRJ45 10/100 BaseT Ethernet adaptive port, built-in 6KV anti-static lightning
protection
Wigan：1 Wiegand output
I/O Port：1 relay output
Memory：Built-in Flash 16G memory
Microphone：Built-in
Speaker：Built-in
General
Operating Temperature：-20°C ~ +60°C
Operating Humidity：0%~90% RH
Consumption：≤5W
Product Size：215 x 125 x 25 mm
Product Weight：<1Kg
Certified：CE｜FCC｜TAF
