Face Recognition Wrist Temperature Detection Tablet
Feature
✅ Starlight High Definition (1920x1080)
✅ H.265/H.264/MJPEG compression coding technology
✅ Human body temperature measurement range -35°C~42°C, accuracy ±0.1°C
✅ Human body temperature overlay, image overlay
✅ Hand temperature detection｜Mask detection
✅ High-precision temperature measurement: ±0.3°C, Taiwan TAF certification
✅ Built-in FACE++ deep learning face recognition algorithm
✅ Support 50,000 face databases
✅ 100ms fast identification
✅ 7-inch high-definition LCD screen
✅ Local alarm output after abnormal temperature
Specification
Model：GK5200RTH
Display
Display Screen：7” LCD
Memory：RAM 8GB｜Flash 16GB
Thermal
Image Sensor：Single point high precision thermal induction infrared temperature sensor
Measuring Range：35°C~+42°C
Measuring distance：10~50 cm, the best distance is 10 cm
Accuracy：± 0.3°C (-10 ~ +50°C)
Camera
Image Sensor：1/2.8” 2MP starlight level low illumination CMOS sensor
Resolution：1920(H) x 1080(V)
Electronic Shutter：1/5~1/20,000s
Min illumination：Color：0.005Lux@F1.2｜B/W：0.001Lux@F1.2
Wide Dynamic：≥100dB
S/N Ratio：≥46dB (AGC OFF)
White Balance：Auto｜indoor｜outdoor｜sodium lamp mode｜manual
D/N Reduction：Support DNR｜3DNR
Day & Night Mode：Fixed color
Lens Type：Fixed lens
focal Length：1.8 mm
Maximum Aperture：F2.0
Field View：118°
Temperature Measurement
Measurement Mode：Support temperature measurement in the whole area and area
Accuracy：Max ±0.3°C
Abnormal Alarm：High temperature/low temperature/temperature difference
Audio&Video
Compression Format：H.265｜H.264｜MJPEG
Image Resolution：Main：1920x1080｜1280x720｜720x576
Sub：640x480｜352x288｜320x240｜176x144
MJPEG：1920x1080｜1280x720｜OFF
Output Bit Rate：Fixed code stream (CBR) or variable code stream (VBR), code stream setting range: 32Kbps~10Mbps
Audio Compression：G711｜PCM
OSD：Support channel name/date/time
Smart Computing
Face Database：Maximum 50,000 sheets, support group management
Recognition Speed：≤100ms
Live Detection：Support
External Port
Power Input：DC12V-2A
Network Port：1xRJ45 10/100 BaseT Ethernet adaptive port, built-in 6KV anti-static lightning protection
Wigan：1 Wiegand output
I/O Port：1 relay output
Memory：Built-in Flash 16G memory
Microphone：Built-in
Speaker：Built-in
General
Operating Temperature：-20°C ~ +60°C
Operating Humidity：0%~90% RH
Consumption：≤5W
Product Size：216 x 125 x 20 mm
Product Weight：<1Kg
Certified：CE｜FCC｜TAF
