Feature
✅ Video Output Mode:5MP(AHD/TVI)@20fps|4M:(CVI)@30fps
✅ 1/3” Low illumination back-illuminated F37P CMOS sensor
✅ Support Warm white (4000K)|Light Distance:up to 30m
✅ 3.6 mm Fixed lens|optional:2.8 /6.0 mm
✅ Protection certification IK10
✅ Support starlight full color
✅ Support WDR
✅ Housing: Metal, IP67
Specification
Model:GK7050ECO-LMDN3-12FP
Image Sensor:1/3” Low illumination back-illuminated F37P CMOS sensor
Master chip:Fullhan FH8538E 5M High Performance ISP
Image Resolution:5M:2592x1944|4M:2560x1440|2M:1920x1080
Video Output Mode:AHD/TVI:5M@20fps|4M@30fps|2M@30fps
CVI:4M@30fps|2M@30fps
TV System:NTSC|PAL
Electronic Shutter:Auto
Minimum Illumination:0.01Lux
Scanning System:Progressive Scan
Focus Length:3.6 mm|optional:2.8 /6.0 mm
Focus Control:Fixed
Lens Type:Fixed
IR Cut Filter:YES
Infrared LED:Support Warm white (4000K)
Light Distance:30M
IR Status:AGC auto control
Starlight:Support
Day/Night:Full color|Black and white
OSD Menu:NO
WDR:Support
UTC:Support
Noise Reduction:AI-DNR
White Balance:AUTO|MANUAL
Gain Control:Auto
Coaxial Audio:No
Material/Color:Metal|White
Waterproof:IP67
Bracket:Yes
Operation Temperature:-30ºC~50ºC|RH50% Max
Storage Temperature:-20ºC~60ºC|RH50% Max
Power Source:DC12V ±10% 450mA
Dimension:⌀ 94 x 72(H) mm
Weight:400g
Certification:CE|FCC|IP67|IK10
