GK7020FMC-LMBM3-00

2MP Analog HD Fixed Miniature Camera

Feature

✅ 1/3" SONY Back-illuminated CMOS sensor
✅ Bright color separation, signal filtering, 2D|3D noise reduction
✅ Full color day and night, the target object can be clearly identified at night
✅ 2MP HD resolution, clear and delicate images
✅ AHD｜TVI｜CVI｜CVBS transmission without delay
✅ Built-in UTC coaxial control, DVR directly controls camera menu settings
✅ Support OSD menu, can be operated remotely via DVR
✅ Built-in DWDR | Strong Light Suppression | Motion Detection | Image Mask
✅ Video system NTSC｜PAL easy switching

Specification

Model：GK7020FMC-LMBM3-00

Image Sensor：1/3" SONY Back-illuminated CMOS sensor

Image Resolution：AHD：2M@30fps/25fps｜CVI：2M@30fps/25fps｜TVI：2M@30fps/25fps

TV System：NTSC｜PAL

Electronic Shutter：Auto

Scanning System：Progressive Scan

Minimum Illumination：Color : 0.01 lux@F2.0, AGC ON｜B/W : 0 lux with IR

Focus Length：Standard: 3.6 mm

Focus Control：Fixed

Lens Type：Fixed

IR Cut Filter：Support

Infrared LED：N/A

Light Distance：N/A

IR Status：N/A

Starlight：N/A

Day/Night：NO

OSD Menu：Support

WDR：DWDR

UTC：Support

Noise Reduction：3DNR

White Balance：Automatic | Manual

Gain Control：Auto

coaxial audio：N/A

Material/Color：Metal｜black

Waterproof coefficient：N/A

Bracket：Yes

Operating Temperature：-10ºC~60ºC｜RH 95% Max

Storage Temperature：-20ºC~60ºC｜RH 95% Max

Power Source：DC12V ±10% 150mA

Dimension：30(W) x 33(H) x 30(D) mm

Weight：150g

Certification：CE｜FCC
