GK7080FMC-LMEM2-00

8MP Analog HD Fixed Miniature Camera

Feature

✅ 1/2.8" SONY Starvis Back-illuminated CMOS sensor
✅ Bright color separation, signal filtering, 2D|3D noise reduction
✅ Full color day and night, the target object can be clearly identified at night
✅ 8MP HD resolution, clear and delicate images
✅ AHD｜TVI｜CVI｜CVBS transmission without delay
✅ Built-in UTC coaxial control, DVR directly controls camera menu settings
✅ Support OSD menu, can be operated remotely via DVR
✅ Built-in DWDR | Strong Light Suppression | Motion Detection | Image Mask
✅ Video system NTSC｜PAL easy switching

Specification

Model：GK7080FMC-LMEM2-00

Image Sensor：1/2.8" SONY Starvis Back-illuminated CMOS sensor

Image Resolution：AHD：8M@15fps｜5M@20fps/12.5fps｜4M/2M@30fps/25fps

CVI：8M@15fps/12.5fps｜4M/2M@30fps/25fps

TVI：8M@15fps/12.5fps｜5M@20fps/12.5fps｜4M/2M@30fps/25fps

TV System：NTSC｜PAL

Electronic Shutter：Auto

Scanning System：Progressive Scan

Minimum Illumination：Color：0.01 Lux@F2.0

Focus Length：Standard: 2.8 mm

Focus Control：Fixed

Lens Type：Fixed

IR Cut Filter：Support

Infrared LED：N/A

Light Distance：N/A

IR Status：N/A

Starlight：N/A

Day/Night：NO

OSD Menu：Support

WDR：120dB

UTC：Support

Noise Reduction：3DNR

White Balance：Automatic | Manual

Gain Control：Auto

coaxial audio：N/A

Material/Color：Metal｜black

Waterproof coefficient：N/A

Bracket：Yes

Operating Temperature：-10ºC~60ºC｜RH 95% Max

Storage Temperature：-20ºC~60ºC｜RH 95% Max

Power Source：DC12V ±10% 150mA

Dimension：32.5(W) x 31.5(H) x 30.5(D) mm

Weight：120g

Certification：CE｜FCC
